CRESCEND P15-2EA1-C5-001 Continuos Duty Cycle Amplifier for 152-162 MHz Input 2-5 Watt / Output 150 Watt (Adjustable) N Females.

     Continuos Duty Cycle CRESCEND Amplifier for Repeaters or Base Stations.

• Ideal for 152-162 MHz Repeaters.
• Duty Cycle: 100 %
• Input/Output Impedance: 50 Ohm.
• Input Power: 2-5 Watt.
• Output Power: 150 Watt.
• Load VSWR Tolerance: VSWR Protected.
• Indicator LEDs: DC On Low Output High VSWR High Temp
• Current Draw: 28 Amp.
• Input/Output Connector: N Female.
• Cooling Method: Fan Forced Air Over Heat Sink.
• Operating Temp. Range: -30 °C to 60 °C
• Humidity: 80% at 40 °C (non-condensing).
• Dimensions (H x W x D): 7" x 19" x 6.0"
• Weight: 10 pounds nominal.

      Ask for delivery time.
